Product Features

• SOUND LEVEL MEASUREMENT
  • Accuracy: IEC 61672 Class 1
  • Dynamic range: 30 to 121dB(A)
  • Frequency range: 20Hz to 20kHz
  • Frequency weighting: A and C weighting Parameters: LEQ, L05, L10, L50, L90, L95, LMAX
• POWER REQUIREMENTS
  • Power input: 110V-240V AC
  • Sonisens: 8 – 16V DC
  • Power consumption: 2 Watts
• COMMUNICATONS
  • Ethernet
  • Wi-Fi (2.4GHz)
  • 4G modem included
• MICROPHONE
  • Sensitivity: 45mV/Pa
  • Connection: SMB to SMB (2m cable as standard)
  • Power supply: Constant current ICP, 18V 4mA

Product Benefits

• LOGGING
  • Measurement period: 1, 5, 10, 15 or 30 minutes
  • Data storage capacity: 5 years (5 minute logging)
  • Procedure: Automatic measurement and logging
• SONITUS CLOUD
  • Includes 2 years subscription to Sonitus Cloud (online data hosting, presentation and analysis)

Aeroqual Air Quality Monitoring Stations

• This sensor can be connected directly to the ePC in the Aeroqual systems to allow real-time noise monitoring data to be displayed alongside air quality and meteorological data
• It is compatible with the following Aeroqual products:
  • AQM65 compact air quality station
  • AQS1 compact air quality monitor
  • Dust Sentry Dust and Particulate Monitor
  • Dust Profiler Dust and Particulate Counter

TYPICAL APPLICATIONS INCLUDE:

• Basic noise measurement
• Environmental noise assessment
• Product quality check
• Evaluation of noise reduction engineering
• Ambient Monitoring
• Environmental Surveys
• Fenceline Monitoring
