Blog

What an Inclinometer Casing Consists Of: An inclinometer casing consists of sections of ABS plastic casing, which has four perpendicular grooves and the associated plastic couplings that have four guide grooves on the inside and two drilling guide holes on the outside at each end. 2 Methods of Attaching Couplings There are two methods of attaching the couplings: The first uses rivets and the tools required for this installation include a hand drill with a one-eighth inch bit, a rivet gun, and one-eighth inch medium sized rivets. The second method...

How to Connect to an Aeroqual AQS1 Monitor or the Aeroqual Dust Sentry Monitor? Here we have the Vaisala weather station and down here, we have the connection for the power and comms. This component here is the one inch pole connector that we will use. Here is the power and comms. And finally on the pole is a one inch pole that we provide to you and a hose clamp. That's connecting that on to our tripod. Step 1 - Attach the Pole Connector All right, so the first...

The Specto Technology team is proud to provide you with the Sonitus EM2030, a fully automated, remote sound level monitor with automatic audio capture and compliance reporting Setting Up A Sonitus Sound Level Monitor (SLM) System First thing to do, take the microphone cable and microphone out of the box. And then we're going to route the microphone cable through the side of the case. Once you got the cable through, you are just going to plug it in to the BNC connector. Then just neaten up that cable. The...

Industrial LTE Gateway - The Airlink Raven RV50 Introducing the AirLink Raven RV50 industrial LTE Gateway, from the market leader in cellular Gateways, Sierra Wireless. The Raven RV50 is industrial grade, specifically designed for operations, and challenging and hazardous environments. Sierra Wireless - Optimized for Solar Applications It is easy to install and is optimized for solar applications. LTE supports low latency polling, and provides the opportunity for new broadband applications, like video and motion sensors, to be added to critical infrastructure. Raven RV50 - Lowest Power LTE The Raven...

Unboxing Our Calibration & Service Kit for the Aeroqual Dust Sentry Today I’m going to be unboxing our calibration and service kit for the Aeroqual Dust Sentry. So let’s have a look inside. We will start with some spares. So we have some spare O-rings for the inlet, some spare keys, some spare screws for the inlet, and some spare luer fittings. Tools wise, we have a long screwdriver for taking modules out. Filters, we have filter pairs for the particulate monitoring. The amount of filters that you have will...

Mini PowerMate Portable Battery Pack: Aeroqual AQS1 & Dust Sentry Monitors The Mini PowerMate is a 15 hour power pack, which we have designed with a lithium-ion battery and AC charger. Take the PowerMate and attach it to the back bracket on the AQS or Dust Sentry monitor Take out DC power cable with Anderson connections. These are waterproof. Blue goes to blue. Attach those and turn on. This power pack will last for about 15 hours. The Mini PowerMate Battery Pack Details Now let's have a look to see...

Connecting a Load Sensing Node We are going to look at how to connect your load sensing node to an external battery. We have three parts to make this happen: We've got a five volt adapter that can hook up directly to a 12 volt battery. We've got a extension cable We have a pass through for USB power to the node on the inside. Disconnecting the USB First, we are going to disconnect the USB from the inside of the Load Sensing node, it is usually plugged in right...

Rail Clip Prism: 25 Millimeter Prism & Anodized Aluminum L-Bar A rail clip prism is made up of two components. We have a high-quality 25 millimeter prism connected to an anodized aluminum L-bar. The rail clip is two parts, stainless steel connected by a stainless steel bolt. And we have another stainless steel bolt connecting the L-bar to the bracket. Preparing the Rail Clip Prism The tools I have for installation today are a socket wrench and two Allen keys. Lets prepare the rail. First, I am going to remove...

Cities are expanding rapidly, not only above, but also underground. They grow through tunneling projects which pose a lot of geotechnical challenges. If you are in charge of a large construction project, you need a reliable instrumentation and monitoring program to reveal hidden threats, to manage risks. The Risk of Collecting Sensor Data Through Manual Readings Most of you install sensors to monitor the behavior of the ground and soil structure interaction. However, the majority of you still collect sensor data through manual readings, which, as you know, is risky...

Sonitus Systems Automated Sound Level Meter - Unboxing Our Sonitus Systems is in the carrying case. First thing we will do, is we are going to open up this case. We've got the EM2030 sound level monitor. EM2030 Sound Level Meter - Antennas This is the actual brains of the operation. It has two antennas; one for wifi and one for cellular. On the bottom, you have a port for the microphone on the right and a port for the power on the left, and then your led indicator on...
